AZ851-24

Zettler SMD PCB relay series AZ851

  • polarized, monostable relays in a compact size (14,2x9,3x6,2mm)
  • with a high sensivity coil (79mW), an epoxy resin seal and 2 changeover contacts (gold-plated)
  • comply with FCC part 68.302 1500V lightning surge
  • contact material: AgPd
  • switching current: 1A
AZ851-24, Zettler SMD relays, 1A, 2 changeover contacts, AZ851 series

AZ851-24

155989 AZ851-24 AZ851-24 Zettler SMD PCB relay series AZ851. polarized, monostable relays in a compact size (14,2x9,3x6,2mm) with a high sensivity coil (79mW), an epoxy resin seal and 2 changeover contacts (gold-plated) comply with FCC part 68.302 1500V lightning surge contact material: AgPd switching current: 1A

Specifications

manufacturer
Manufacturer's name AZ851-24
Min. operating voltage [V] 18
Coil resistance [Ω] 2880
Max. operating voltage [V] 48
Nominal capacity [mW] 200
Data Sheet

Unit price

1,58 €

Stock: 310
Further delivery:
CW 13/2025

Minimum order quantity 5 units or
multiples of 5.
