AZ851-12

Zettler SMD PCB relay series AZ851

  • polarized, monostable relays in a compact size (14,2x9,3x6,2mm)
  • with a high sensivity coil (79mW), an epoxy resin seal and 2 changeover contacts (gold-plated)
  • comply with FCC part 68.302 1500V lightning surge
  • contact material: AgPd
  • switching current: 1A
AZ851-12, Zettler SMD relays, 1A, 2 changeover contacts, AZ851 series

AZ851-12

155988 AZ851-12 AZ851-12 Zettler SMD PCB relay series AZ851. polarized, monostable relays in a compact size (14,2x9,3x6,2mm) with a high sensivity coil (79mW), an epoxy resin seal and 2 changeover contacts (gold-plated) comply with FCC part 68.302 1500V lightning surge contact material: AgPd switching current: 1A

Specifications

manufacturer
Manufacturer's name AZ851-12
Min. operating voltage [V] 9
Coil resistance [Ω] 1028
Max. operating voltage [V] 30
Nominal capacity [mW] 140
Data Sheet

Unit price

1,51 €

Stock: 80
Next incoming goods:
CW 06/2025
1000 units

Further delivery:
CW 17/2025

Minimum order quantity 5 units or
multiples of 5.
