250-211

spring force terminals series 250 by Wago

• with lever
• conductor: 45°
• pitch: 3.5mm
• staggered poles
• 11-pole
• by Wago
• rated voltage: 250V
• rated current: 8A
• rated cross section single and fine stranded wire: 0.2 to 1.5mm2
• stripped length: 8.5 to 9.5mm
• insulating material: PA 6.6
• temperature range: -60 to +105°C
• flammability class: UL94V-0
• colour: grey

series 250 by Wago

250-211

41860 250-211 250-211 spring force terminals series 250 by Wago. • with lever• conductor: 45°• pitch: 3.5mm• staggered poles• 11-pole• by Wago• rated voltage: 250V• rated current: 8A• rated cross section single and fine stranded wire: 0.2 to 1.5mm2• stripped length: 8.5 to 9.5mm• insulating material: PA 6.6• temperature range: -60 to +105°C• flammability class: UL94V-0• colour: grey

Specifications

manufacturer
Manufacturer's name 250-211
Design with lever
Length [mm] 40
Data Sheet

Unit price

1,98 €

Stock: 80
Further delivery:
CW 01/2025

Minimum order quantity 5 units or
multiples of 5.
