> Passive elements>Potentiometers>Trimmer potentiometers>Vishay SMD multiturn trimmers, 0,25W, 1,4", TS63Y series>64 Y 50 k SMD

Manufacturers

64 Y 50 k SMD

0.25 W, SMD

• standard tolerance: ±10%
• resistive element: cermet
• temperature range: -55...+155°C
• climatic category: 55/125/56
• sealing: IP67
• mechanical travel: 15 ±5
• operating torque, end position: clutch action
• operating torque (max.): 1.5Ncm
• weight: 0.5
Vishay series TS63Y

64 Y 50 k SMD

6195 64 Y 50 k SMD TS63Y503KT20 TS63Y503KT20 0.25 W, SMD. * standard tolerance: ±10%* resistive element: cermet* temperature range: -55...+155°C* climatic category: 55/125/56* sealing: IP67* mechanical travel: 15 ±5* operating torque, end position: clutch action* operating torque (max.): 1.5Ncm* weight: 0.5

Specifications

manufacturer
Manufacturer's name TS63Y503KT20
Resistance [Ω] 50k
Power, max. [W] 0,25
Data Sheet

Unit price

2,19 €

Stock: 470
Further delivery:
CW 34/2025

Minimum order quantity 10 units or
multiples of 10.
