P11VYN001K10%A

cermet precision potetiometer

• linear
• power rating (TU = 70°C): 1W
• shaft: metal Ø6mm
• housing: 12.5x12.5mm
• hold-off voltage: 350V
• dielectric strength (RMS): 1500V
• insulation resistance, min.: 106
• standard tolerance: ±10%
• resistive element: cermet
• end resistance (typ.): 2Ω
• electrical travel: 270° ±10°
• mechanical travel: 300° ±5°
• operating torque, max.: 0.4...1.8Ncm
• stop end torque, max.: 80Ncm
• temperature range: -55...+125°C
• temperature coefficient (typ.): ±150ppm/°C
• climatic category: 55/125/56
• sealing: IP64
• by vishay

P11VYN001K10%A

29939 P11VYN001K10%A P11S1V0FLSY00102KA P11S1V0FLSY00102KA cermet precision potetiometer. • linear• power rating (TU = 70°C): 1W• shaft: metal Ø6mm• housing: 12.5x12.5mm• hold-off voltage: 350V• dielectric strength (RMS): 1500V• insulation resistance, min.: 106MΩ• standard tolerance: ±10%• resistive element: cermet• end resistance (typ.): 2Ω• electrical travel: 270° ±10°• mechanical travel: 300° ±5°• operating torque, max.: 0.4...1.8Ncm• stop end torque, max.: 80Ncm• temperature range: -55...+125°C• temperature coefficient (typ.): ±150ppm/°C• climatic category: 55/125/56• sealing: IP64• by vishay

Specifications

manufacturer
Manufacturer's name P11S1V0FLSY00102KA
Resistance [Ω] 1k
Power, max. [W] 1
Transmission current, max. [mA] 31,6
Max. operating voltage [V] 31,6
Data Sheet

Unit price

7,59 €

Stock: 108
Next incoming goods:
CW 06/2025
20 units


Further delivery:
CW 10/2025
