UP62 110°

thermostats UP62 by Uchiya

• contact: NC
• housing: PBT
• switch-off tolerance: ±5K
• standard differential: 30 ±15K
• rated voltage: 250V
• rated current: 2.5A
• long terminal wires: 100mm
• insulation class: IP00
• insulation resistance: 100MΩ
• high voltage insulation: 2.5kV
• by Uchiya

UP62 110°

44597 UP62 110° UP62-110-05-100 UP62-110-05-100 thermostats UP62 by Uchiya. * contact: NC* housing: PBT* switch-off tolerance: ±5K* standard differential: 30 ±15K* rated voltage: 250V* rated current: 2.5A* long terminal wires: 100mm* insulation class: IP00* insulation resistance: 100MΩ* high voltage insulation: 2.5kV* by Uchiya

Specifications

manufacturer
Manufacturer's name UP62-110-05-100
Data Sheet

Unit price

2,09 €

Stock: 130
Further delivery:
CW 06/2025

Minimum order quantity 5 units or
multiples of 5.
