> Passive elements>Inductors>Storage chokes>Talema SMD inductors, LC series>LP-SMD 100 µH/0,44 A

Manufacturers

LP-SMD 100 µH/0,44 A

storage chokes for DC/DC converters

* operating frequency up to 1MHz
* high stability
* gold-plated terminal pads ensure excellent solderability
* test voltage between windings 500Vrms
LP-SMD

LP-SMD 100 µH/0,44 A

6509 LP-SMD 100 µH/0,44 A LP-SMD 100 µH/0,44 A storage chokes for DC/DC converters. * operating frequency up to 1MHz* high stability* gold-plated terminal pads ensure excellent solderability* test voltage between windings 500Vrms

Discontinued items. Only remainder of stock available.

Specifications

Rated current [mA] 440
Inductance [µH] 100
DC resistance [Ω] 376
Stored energy [µJ] 7,2
Data Sheet

Unit price

1,09 €

Stock: 5
