CAX-1,1-6,8

Talema choke series CA

Current-compensated chokes in a partially pottes housing. These inductors have a vertical design and have two separate windings for a low capacitive resistance. They are suitable for an operating temperature range of -40 to +125°C and have four soldering pins (0,6x0,88mm). We offer various types of this Talema series.

  • vertical
  • partially potted
  • test voltage: 1500V AC (60sec)
  • operating temperature: -40 to +125°C
CAX-1,1-6,8, Talema current-compensated chokes, partially potted, vertical, CA series

CAX-1,1-6,8

244156 CAX-1,1-6,8 CAX-1,1-6,8 Talema choke series CA. Current-compensated chokes in a partially pottes housing. These inductors have a vertical design and have two separate windings for a low capacitive resistance. They are suitable for an operating temperature range of -40 to +125°C and have four soldering pins (0,6x0,88mm). We offer various types of this Talema series. vertical partially potted test voltage: 1500V AC (60sec) operating temperature: -40 to +125°C

Specifications

manufacturer
Manufacturer's name CAX-1,1-6,8
Rated current [mA] 1100
Internal resistance [mΩ] 342
Rated inductance [mH] 6,8
Data Sheet

Unit price

1,58 €

Stock: 0
Next incoming goods:
CW 49/2024
1250 units

Minimum order quantity 10 units or
multiples of 10.
