DF 10 Mini

SMD bridge rectifiers 0.5A

• glass passivated
• SMD housing
• by Taiwan Semiconductor
• leads solderable per MIL-STD-202, meth. 208
• solderability, max.: 250°C/10s
• operating temperature range: up -55 to +150°C

DF 10 Mini

25785 DF 10 Mini MBS10 MBS10 SMD bridge rectifiers 0.5A. • glass passivated• SMD housing• by Taiwan Semiconductor• leads solderable per MIL-STD-202, meth. 208• solderability, max.: 250°C/10s• operating temperature range: up -55 to +150°C

Specifications

manufacturer
Manufacturer's name MBS10
Case SMD
(Max.) peak recurrent reverse voltage [V] 1000
Forward voltage [V] 1
(Max.) average forward (rectified) current [A] 0,5
Reverse current [µA] 5
(Max.) RMS voltage [V] 700
Data Sheet

Unit price

0,102 €

Stock: 76004
Further delivery:
CW 07/2025

Minimum order quantity 1 to 4 units or multiples of 100 plus 0 to 4 .
