DBLS 203 G

Taiwan Semiconductor SMD rectifier series DBLS

  • SMD bridge rectifiers
  • suitable for direct PCB mounting
  • glass passivated
  • solderable according to MIL-STD-202, Meth. 208
  • solderability: max. 260°C/10s
  • operating temperature: -55 to +150°C

DBLS 203 G

45937 DBLS 203 G DBLS203G DBLS203G Taiwan Semiconductor SMD rectifier series DBLS. SMD bridge rectifiers  suitable for direct PCB mounting  glass passivated solderable according to MIL-STD-202, Meth. 208 solderability: max. 260°C/10s operating temperature: -55 to +150°C

Specifications

manufacturer
Manufacturer's name DBLS203G
Case SMD
(Max.) peak recurrent reverse voltage [V] 200
Forward voltage [V] 1,15
Reverse current [µA] 10
(Max.) average forward (rectified) current [A] 2
(Max.) RMS voltage [V] 140
Data Sheet

Unit price

0,278 €

Stock: 22243
Further delivery:
CW 07/2025

Minimum order quantity 1 to 18 units or multiples of 25 plus 0 to 18 .
