TS13AE1J470MSB000R

Suntan capacitor series TS13AE

Axial type electrolytic capacitors with a service life of up to 2.000h at a temperature of +85°C. These devices have an anode electrode made of an aluminium foil and are suitable for various applications. They have a capacitance tolerance of ±20% as well as a wide temperature range from -40 to +85°C. We offer various types of this Suntan series.

  • rated voltage: 16 to 63V DC
  • capacity: 2,2 to 4700µF
  • capacitance tolerance: ±20%
  • operating temperature: -40 to +85°C
  • bulk
TS13AE1J470MSB000R, Suntan electrolytic capacitors, axial, 85°C, TS13AE series

TS13AE1J470MSB000R

243571 TS13AE1J470MSB000R TS13AE1J470MSB000R Suntan capacitor series TS13AE. Axial type electrolytic capacitors with a service life of up to 2.000h at a temperature of +85°C. These devices have an anode electrode made of an aluminium foil and are suitable for various applications. They have a capacitance tolerance of ±20% as well as a wide temperature range from -40 to +85°C. We offer various types of this Suntan series. rated voltage: 16 to 63V DC capacity: 2,2 to 4700µF capacitance tolerance: ±20% operating temperature: -40 to +85°C bulk

Specifications

manufacturer
Manufacturer's name TS13AE1J470MSB000R
Nominal voltage [V DC] 63
Capacity [µF] 47
D x L [mm] 8x16
Data Sheet

Unit price

0,28 €

Stock: 410
Further delivery:
CW 04/2025

Minimum order quantity 10 units or
multiples of 10.
