MF 30060 V1-1000U-A99

Sunon fan series MF

Fans with a size of 30x30x6mm and rated voltage of 5V DC. These fans are equipped with a 4-pole DC motor, vapor bearings and a magnetic levitation system.The impeller and frame are made of thermoplastic PBT (UL94V-0). They are connected through UL1571 AWG28 wires.

MF 30060 V1-1000U-A99

111071 MF 30060 V1-1000U-A99 MF30060V1-1000U-A99 MF30060V1-1000U-A99 Sunon fan series MF. Fans with a size of 30x30x6mm and rated voltage of 5V DC. These fans are equipped with a 4-pole DC motor, vapor bearings and a magnetic levitation system.The impeller and frame are made of thermoplastic PBT (UL94V-0). They are connected through UL1571 AWG28 wires.

Specifications

manufacturer
Manufacturer's name MF30060V1-10...
Current [A] 0,112
Dimensions 30x30x6
Nominal voltage [V] 5
Electric power [W] 0,56
Noise [dBA] 23,6
Air performance [m3/h] 8,32
Number of revolutions [U/min] 9100
Data Sheet

Unit price

5,49 €

Stock: 764
Next incoming goods:
CW 02/2025
730 units


Further delivery:
CW 18/2025
