DP203A2123LBT.S.GN

Sunon fan 230V and 115V AC series DP/A/SF/SP

AC fans with a diecast aluminium frame and an impedance protected shaded-pole motor. These fans feature impellers made of thermoplastic PBT (UL94V-0) and can operate in temperatures ranging from -10 to +70°C. With dimensions of 120x120x38mm, they have a rated voltage of 115V AC (SP_) resp. 15/230V AC (SF_)


DP203A2123LBT.S.GN DP203A-2123LBT.S.GN

DP203A2123LBT.S.GN

234643 DP203A2123LBT.S.GN DP203A-2123LBT.S.GN DP203A-2123LBT.S.GN Sunon fan 230V and 115V AC series DP/A/SF/SP. AC fans with a diecast aluminium frame and an impedance protected shaded-pole motor. These fans feature impellers made of thermoplastic PBT (UL94V-0) and can operate in temperatures ranging from -10 to +70°C. With dimensions of 120x120x38mm, they have a rated voltage of 115V AC (SP_) resp. 15/230V AC (SF_)

Specifications

manufacturer
Manufacturer's name DP203A-2123L...
Current [A] 0,048
Bearing ball bearing
Dimensions 120x120x38mm
Nominal voltage [V] 230V AC
Electric power [W] 10,9
Noise [dBA] 39
Air performance [m3/h] 132,49
Number of revolutions [U/min] 2300
Data Sheet

Unit price

12,99 €

Stock: 37
Further delivery:
CW 14/2025
