DP201A2123HBL.GN

Sunon fan 230V and 115V AC series DP/A/SF/SP

AC fans with a diecast aluminium frame and an impedance protected shaded-pole motor. These fans feature impellers made of thermoplastic PBT (UL94V-0) and can operate in temperatures ranging from -10 to +70°C. With dimensions of 120x120x38mm, they have a rated voltage of 115V AC (SP_) resp. 15/230V AC (SF_)

A12003200G-00, Sunon fans, 120x120x38mm, 230/115V AC, DP/A/SF/SP series

DP201A2123HBL.GN

234637 DP201A2123HBL.GN DP201A-2123HBL.GN DP201A-2123HBL.GN Sunon fan 230V and 115V AC series DP/A/SF/SP. AC fans with a diecast aluminium frame and an impedance protected shaded-pole motor. These fans feature impellers made of thermoplastic PBT (UL94V-0) and can operate in temperatures ranging from -10 to +70°C. With dimensions of 120x120x38mm, they have a rated voltage of 115V AC (SP_) resp. 15/230V AC (SF_)

Specifications

manufacturer
Manufacturer's name DP201A-2123HBL.GN
Current [A] 0,125
Bearing ball bearing
Dimensions 120x120x38mm
Nominal voltage [V] 230V AC
Electric power [W] 20
Noise [dBA] 45
Air performance [m3/h] 147,77
Number of revolutions [U/min] 2750
Data Sheet

Unit price

15,89 €

Stock: 0
Next incoming goods:
CW 02/2025
200 units

Further delivery:
CW 14/2025
