MRT1 P5/2 grau

spring force terminals MRT1 P5 by Stelvio Kontek

• with lever
• conductor: horizontal
• pitch: 5mm
• 2-pole
• by Stelvio Kontek
• rated voltage (EN 60998): 250V AC
• rated current: 10A
• rated cross section single and fine stranded wire: 0,5 to 1,5mm²
• stripped length: 10mm
• insulating material: PA
• temperature range: -30 to +120°C
• flammability class: UL94V-0
• colour: grey

MRT1 P5/2 grau by Stelvio Kontek

MRT1 P5/2 grau

39274 MRT1 P5/2 grau MRT1P5/2GR MRT1P5/2GR spring force terminals MRT1 P5 by Stelvio Kontek. • with lever• conductor: horizontal• pitch: 5mm• 2-pole• by Stelvio Kontek• rated voltage (EN 60998): 250V AC• rated current: 10A• rated cross section single and fine stranded wire: 0,5 to 1,5mm²• stripped length: 10mm• insulating material: PA• temperature range: -30 to +120°C• flammability class: UL94V-0• colour: grey

Discontinued items. Only remainder of stock available.

Specifications

manufacturer
Manufacturer's name MRT1P5/2GR
Design with lever
Length [mm] 11,5
Data Sheet

Unit price

0,29 €

Stock: 1
