> Passive elements>IDC connectors>IDC male headers, pitch: 2.54mm>Speed box headers, pitch 2,54mm, angled, SPMH series>ML 10 A

Manufacturers

ML 10 A

multipole connectors

• angled
• colour: grey
• without locking levers
• pitch: 2.54mm
• PBT 20% glass fibre
• contacts: copper alloy
• contact surface: gold over nickel
• rated current: 1A
• contact resistance: 20mΩ
• insulation resistance (500V DC), min: 5000MΩ
• temperature range: -25...+85°C

MLW 20 A

ML 10 A

11724 ML 10 A SPMH10A-3000 SPMH10A-3000 multipole connectors. • angled• colour: grey• without locking levers• pitch: 2.54mm• PBT 20% glass fibre• contacts: copper alloy• contact surface: gold over nickel• rated current: 1A• contact resistance: 20mΩ• insulation resistance (500V DC), min: 5000MΩ• temperature range: -25...+85°C

Specifications

manufacturer
Manufacturer's name SPMH10A-3000
Number of poles 10
A [mm] 32,2
Width [mm] 21,84

Unit price

0,669 €

Stock: 907
Further delivery:
CW 01/2024

Minimum order quantity 1 to 7 units or multiples of 10 plus 0 to 7 .
