> Passive elements>Fuses>SMD micro fuses>Siba SMD fuses, very fast acting, 0603 housing, 152000 series>S-SMD FF 500 mA 0603

Manufacturers

S-SMD FF 500 mA 0603

SMD fuses 0603

* cylindrical version, 8.4mm diameter
* thermoplastic housing, temperature resistant, self-extinguishing
* short radial terminals (4.3mm, Ø 0.6mm), tinned
* solder or plug-in
* rated voltage: 250V
* rated breaking capacity
up to 3.15A (@ AC 250V): 35A
4A (@ AC 250V): 40A
5A (@ AC 250V): 50A
* fusing time limits
50mA...6.3A
1.5xIN, min: 1h
2.1xIN, max.: 30min.
2.75xIN: 10ms...3s
4xIN: 3ms...300ms
10xIN, max.: 20ms
* dimensions(LxWxT): 1.55x0.85x0.45mm: W1=75% von W, T1/T2=0.3mm
S-SMD FF _ 0603

S-SMD FF 500 mA 0603

27304 S-SMD FF 500 mA 0603 152000.0,5GT-1K 152000.0,5GT-1K SMD fuses 0603. * cylindrical version, 8.4mm diameter* thermoplastic housing, temperature resistant, self-extinguishing* short radial terminals (4.3mm, Ø 0.6mm), tinned* solder or plug-in* rated voltage: 250V* rated breaking capacityup to 3.15A (@ AC 250V): 35A4A (@ AC 250V): 40A5A (@ AC 250V): 50A* fusing time limits50mA...6.3A1.5xIN, min: 1h2.1xIN, max.: 30min.2.75xIN: 10ms...3s4xIN: 3ms...300ms10xIN, max.: 20ms* dimensions(LxWxT): 1.55x0.85x0.45mm: W1=75% von W, T1/T2=0.3mm

Specifications

manufacturer
Manufacturer's name 152000.0,5GT-1K
Design very fast acting
Rated current [mA] 500
Data Sheet

Unit price

0,39 €

Stock: 1090
Further delivery:
CW 06/2025

Minimum order quantity 1 to 90 units or multiples of 100 plus 0 to 90 .
