SLT80-700IL-EU

Self LED driver series SLT80-IL-EU

LED drivers in a non-insulated plastic case (IP20) with 80W and a constant current. These devices are suitable for LED lighting applications and are protected against overload, overtemperature as well as short circuit. They are not dimmable and comply with EN61347-1, EN61347-2-13, EN55015 as well as EN61000-3-2. We offer the following types of this Self series: SLT80-350IL-EU and SLT80-700IL-EU.

  • single output
  • output: 80W
  • input voltage: 220 to 240V AC
  • input inrush current: 40A
  • operating temperature: -20 to +50°C
  • service life (Tc=90°C): 50.000h
  • weight SLT80-350IL-EU: 210g
  • weight SLT80-700IL-EU: 230g
SLT80-700IL-EU, Self LED switching power supplies, 80W, IP20, constant current CC, SLT80-IL-EU series

SLT80-700IL-EU

126936 SLT80-700IL-EU SLT80-700IL-EU Self LED driver series SLT80-IL-EU. LED drivers in a non-insulated plastic case (IP20) with 80W and a constant current. These devices are suitable for LED lighting applications and are protected against overload, overtemperature as well as short circuit. They are not dimmable and comply with EN61347-1, EN61347-2-13, EN55015 as well as EN61000-3-2. We offer the following types of this Self series: SLT80-350IL-EU and SLT80-700IL-EU. single output output: 80W input voltage: 220 to 240V AC input inrush current: 40A operating temperature: -20 to +50°C service life (Tc=90°C): 50.000h weight SLT80-350IL-EU: 210g weight SLT80-700IL-EU: 230g

Specifications

manufacturer
Manufacturer's name SLT80-700IL-EU
Efficiency [%] 93,4
Output power [W] 80
Output current [mA] 700
Ripple & noise [%] 3
Output voltage range [V] 60...114
Data Sheet

Unit price

13,59 €

Volume discounts

Quantity Unit price
100 + 11,59 €
50 + 12,09 €

Stock: 89
Next incoming goods:
CW 04/2025
50 units

Further delivery:
CW 16/2025
