SLT75-24VFG

Self LED driver series SLT75-VFG

Flickerfree LED drivers in a plastic housing (IP20) with 75W, a constant voltage and protection class II. These SELV compliant devices are suitable for LED lighting applications and are protected against overload, overvoltage, overtemperature as well as short circuit. They are not dimmable and comply with EN55015, EN61347-1 as well as EN61347-2-13. We offer the following types of this Self series: SLT75-12VFG and SLT75-24VFG.

  • single output
  • output: 75W
  • input voltage: 220 to 240V AC
  • maximal input inrush current: 46A
  • no-load power: <0,5W
  • service life: 30.000h (Tc = 90°C)
  • operating temperature: -20 to +45°C
  • dimensions: 289x30x16,5mm
  • weight: 162g
SLT75-24VFG

SLT75-24VFG

109508 SLT75-24VFG SLT75-24VFG Self LED driver series SLT75-VFG. Flickerfree LED drivers in a plastic housing (IP20) with 75W, a constant voltage and protection class II. These SELV&nbsp;compliant devices are suitable for LED lighting applications and are protected against overload, overvoltage, overtemperature as well as short circuit. They are not dimmable and comply with&nbsp;EN55015, EN61347-1 as well as EN61347-2-13. We offer the&nbsp;following types of this Self series:&nbsp;SLT75-12VFG and SLT75-24VFG. single output output: 75W input voltage: 220 to 240V AC maximal input inrush current: 46A no-load power: &lt;0,5W service life: 30.000h (Tc = 90&deg;C) operating temperature: -20 to +45&deg;C dimensions: 289x30x16,5mm weight: 162g

Specifications

manufacturer
Manufacturer's name SLT75-24VFG
Output voltage [V] 24
Efficiency [%] 90
Output current [A] 0...3,1
Output power [W] 75
Ripple [mVp-p] 200
