SLT250-48VFG-EU

Self LED driver series SLT250-VFG-EU

Flickerfree LED drivers in a plastic case (IP20) with 250W, a constant voltage and protection class II. These devices are suitable for LED lighting applications and are protected against short circuit, overload as well as overtemperature. They are not dimmable and comply with EN61347-1, EN61347-2-13, EN55015 as well as EN61000-3-2. We offer the following types of this Self series: SLT250-24VFG-EU and SLT250-48VFG-EU.

  • single output
  • output: 30 to 250W
  • input voltage: 220 to 240V AC (50 or 60Hz), 176 to 280V DC
  • maximal input inrush current: 130A
  • operating temperature: -20 to +40°C
  • service life (Tc = 90°C): 50.000h
  • weight: 400g
SLT250-48VFG-EU, Self LED drivers, 250W, IP20, constant voltage, SLT250-VFG-EU series

SLT250-48VFG-EU

138342 SLT250-48VFG-EU SLT250-48VFG-EU Self LED driver series SLT250-VFG-EU. Flickerfree LED drivers in a plastic case (IP20) with 250W, a constant voltage and protection class II. These devices are suitable for LED lighting applications and are protected against short circuit, overload as well as overtemperature. They are not dimmable and comply with EN61347-1, EN61347-2-13, EN55015 as well as EN61000-3-2. We offer the following types of this Self series: SLT250-24VFG-EU and SLT250-48VFG-EU.  single output output: 30 to 250W input voltage: 220 to 240V AC (50 or 60Hz), 176 to 280V DC maximal input inrush current: 130A operating temperature: -20 to +40°C service life (Tc = 90°C): 50.000h weight: 400g

Specifications

manufacturer
Manufacturer's name SLT250-48VFG-EU
Output voltage [V] 48
Efficiency [%] 94
Output current range [A] 0,625...5,2
Output power [W] 30...250
Ripple [mVp-p] 600
Data Sheet

Unit price

52,19 €

Volume discounts

Quantity Unit price
100 + 47,69 €
50 + 49,69 €

Stock: 32
Further delivery:
CW 11/2025
