SLT150-24VFG-UN

Self LED driver series SLT150-VFG-UN

LED drivers in a plastic housing (IP20) with 150W, protection class II, a constant voltage (CV) and a low no-load power consumption. These SELV compliant devices are suitable for LED lighting applications and are protected against short circuit, overload as well as overtemperature. They are not dimmable and comply with EN61347-1, EN61347-2-13, UL8750 as well as EN55015. We offer the following types of this Self series: SLT150-24VFG-UN and SLT150-48VFG-UN.

  • single output
  • output: 150W
  • input voltage: 108 to 264V AC (50 to 60Hz), 176 to 280V DC
  • input current: 1,4A
  • input inrush current: 130A
  • no-load power consumption: <0,5W
  • operating temperature: -20 to +45°C
  • service life: 50.000h
  • dimensions: 369x30x22mm
  • weight: 400g
SLT150-24VFG-UN, Self LED drivers, 150W, IP20, constant voltage, SLT150-VFG-UN series

SLT150-24VFG-UN

238204 SLT150-24VFG-UN SLT150-24VFG-UN Self LED driver series SLT150-VFG-UN. LED&nbsp;drivers in a plastic housing (IP20) with 150W, protection class II, a constant voltage (CV) and a low no-load power&nbsp;consumption. These SELV compliant devices are&nbsp;suitable for LED lighting applications and are&nbsp;protected&nbsp;against short circuit, overload as well as overtemperature. They are not dimmable and comply with&nbsp;EN61347-1, EN61347-2-13, UL8750 as well as EN55015. We offer the following types of this Self series:&nbsp;SLT150-24VFG-UN and SLT150-48VFG-UN. single output output: 150W input voltage: 108 to 264V AC (50 to 60Hz), 176 to 280V DC input current: 1,4A input inrush current: 130A no-load power consumption: &lt;0,5W operating temperature: -20 to +45&deg;C service life: 50.000h dimensions: 369x30x22mm weight: 400g

Specifications

manufacturer
Manufacturer's name SLT150-24VFG-UN
Output voltage [V] 24
Efficiency [%] 94
Output current [A] 6,25
Output power [W] 150
Ripple [mVp-p] 400
Data Sheet

Unit price

45,19 €

Volume discounts

Quantity Unit price
100 + 41,29 €
50 + 43,09 €

Stock: 106
Next incoming goods:
CW 04/2025
70 units

Further delivery:
CW 11/2025
