SLT100-24VFG-UN

Self LED driver series SLT100-VFG-UN

LED drivers in a plastic case (IP20) with 100W, a constant voltage and protection class II. These SELV compliant devices are protected against short circuit, overload, overvoltage as well as overtemperature. They are suitable for LED lighting applications and comply with EN61347-1, EN61347-2-13, EN55015 as well as EN61000-3-2. We offer the types SLT100-24VFG-UN and SLT100-48VFG-UN of this Self series.

  • single output
  • output: 100W
  • input voltage: 120 to 240V AC
  • maximal input inrush current SLT100-24_: 38,2A
  • maximal input inrush current SLT100-48_: 37A
  • operating temperature: -20 to +45°C
  • service life (Tc = 90°C): 50.000h
  • weight: 216g
SLT100-24VFG-UN, Self LED drivers, 100W, IP20, constant voltage, SLT100-VFG-UN series

SLT100-24VFG-UN

110872 SLT100-24VFG-UN SLT100-24VFG-UN Self LED driver series SLT100-VFG-UN. LED drivers in a plastic case (IP20) with 100W, a constant voltage and protection class II. These SELV compliant devices are protected against short circuit, overload, overvoltage as well as overtemperature. They are suitable for LED lighting applications and comply with EN61347-1, EN61347-2-13, EN55015 as well as EN61000-3-2. We offer the types SLT100-24VFG-UN and SLT100-48VFG-UN of this Self series. single output output: 100W input voltage: 120 to 240V AC maximal input inrush current SLT100-24_: 38,2A maximal input inrush current SLT100-48_: 37A operating temperature: -20 to +45°C service life (Tc = 90°C): 50.000h weight: 216g

Specifications

manufacturer
Manufacturer's name SLT100-24VFG-UN
Output voltage [V] 24
Efficiency [%] 92,3
Output current [A] 0...4,17
Output power [W] 100
Ripple [mVp-p] 800
Data Sheet

Unit price

28,89 €

Volume discounts

Quantity Unit price
100 + 25,59 €
50 + 26,59 €

Stock: 106
Next incoming goods:
CW 04/2025
500 units

Further delivery:
CW 16/2025
