SLT100-24VLG-E

Self LED driver series SLT100-24VLG-E

LED drivers in a plastic housing (IP20) with 100W, a constant voltage and protection class II. These SELV compliant devices are suitable for LED lighting applications and are protected against overload, overtemperature as well as short circuit. They have a low no-load power (<0,5W) and comply with EN61347-1, EN61347-2-13 as well as EN55015. We offer the type SLT100-24VLG-E of this Self series.

  • single output
  • output: 100W
  • input voltage: 198 to 264V AC (50/60Hz)
  • maximal input inrush current: 120A
  • service life: 50.000h
  • operating temperature: -20 to +45°C
  • dimensions: 188x45x30mm
  • weight: 330g
SLT100-24VLG-E, Self LED drivers, 100W, IP20, constant voltage, SLT100-24VLG-E series

SLT100-24VLG-E

242212 SLT100-24VLG-E SLT100-24VLG-E Self LED driver series SLT100-24VLG-E. LED drivers in a plastic housing (IP20) with 100W, a constant voltage and protection class II. These SELV compliant devices are suitable for LED lighting applications and are protected against overload, overtemperature as well as short circuit. They have a low no-load power (&lt;0,5W) and comply with EN61347-1, EN61347-2-13 as well as EN55015. We offer the type SLT100-24VLG-E of this Self series. single output output: 100W input voltage: 198 to 264V AC (50/60Hz) maximal input inrush current: 120A service life: 50.000h operating temperature: -20 to +45°C dimensions: 188x45x30mm weight: 330g

Specifications

manufacturer
Manufacturer's name SLT100-24VLG-E
Output voltage [V] 24
Efficiency [%] 92
Output current range [A] 0...4,16
Output power [W] 100
Ripple [mVp-p] 400
Data Sheet

Unit price

27,69 €

Volume discounts

Quantity Unit price
100 + 24,39 €
50 + 25,39 €

Stock: 0
Next incoming goods:
CW 04/2025
16 units

Further delivery:
CW 16/2025
