> Power supplies>Power supplies>Switching power supplies for illumination, LED>Self LED drivers, 75W, IP20, constant voltage, dimmable, SLD75-VL-E series>SLD75-12VL-E

Manufacturers

SLD75-12VL-E

Self LED driver series SLD75-VL-E

Flickerfree LED drivers in a plastic housing (IP20) with 75W, a constant voltage and protection class II. These SELV compliant devices have a TRIAC dimmer (phase-cut dimmers) and are protected against overload, overtemperature, overvoltage as well as short circuit. They are suitable for LED lighting applications and comply with EN55015, EN61347-1, EN61347-2-13 as well as EN61000-3-2. We offer the following types of this Self series: SLD75-12VL-E and SLD75-24VL-E.

  • single output
  • output: 75W
  • input voltage: 220 to 240V AC
  • maximal input inrush current: 30A
  • service life: 30.000h (Tc = 45°C)
  • operating temperature: -10 to +45°C
  • dimensions: 185x60x31mm
  • weight: 430g
SLD75-12VL-E

SLD75-12VL-E

109134 SLD75-12VL-E SLD75-12VL-E Self LED driver series SLD75-VL-E. Flickerfree LED drivers in a plastic housing (IP20) with 75W, a constant voltage and protection class II. These SELV compliant devices have a TRIAC dimmer (phase-cut dimmers) and are protected against overload, overtemperature, overvoltage as well as short circuit. They are suitable for LED lighting applications and comply with EN55015, EN61347-1, EN61347-2-13 as well as EN61000-3-2. We offer the following types of this Self series: SLD75-12VL-E and SLD75-24VL-E. single output output: 75W input voltage: 220 to 240V AC maximal input inrush current: 30A service life: 30.000h (Tc = 45°C) operating temperature: -10 to +45°C dimensions: 185x60x31mm weight: 430g

Specifications

manufacturer
Manufacturer's name SLD75-12VL-E
Output voltage [V] 12
Efficiency [%] 85
Output current [A] 1...6,25
Output power [W] 75
Ripple [mVp-p] 300
Data Sheet

Unit price

39,69 €

Volume discounts

Quantity Unit price
100 + 36,19 €
50 + 37,79 €

Stock: 120
Further delivery:
CW 11/2025
