SLD15-700IL-ES

Self LED driver series SLD-15-IL-ES

Flickerfree LED drivers in a plastic housing (IP20) with 15W, a constant current and protection class II. These SELV compliant devices are suitable for LED lighting applications and are protected against overload, overvoltage, overtemperature as well as short circuit. They are dimmable and comply with EN55015, EN61347-1 as well as EN61347-2-13. We offer the following types of this Self series: SLD15-300IL-ES, SLD15-350IL-ES, SLD15-500IL-ES and SLD15-700IL-ES.

  • single output
  • output: 15W
  • input voltage: 220 to 240V AC
  • maximal input inrush current: 2A
  • operating temperature: -25 to +50°C
  • service life: 50.000h (Tc = 85°C)
  • dimensions: 85,3x41x22mm
  • weight: 95g
Mean Well SLD15-IL-ES series

SLD15-700IL-ES

111630 SLD15-700IL-ES SLD15-700IL-ES Self LED driver series SLD-15-IL-ES. Flickerfree LED drivers in a plastic housing (IP20) with 15W, a constant current and protection class II. These SELV compliant devices are suitable for LED lighting applications and are protected against overload, overvoltage, overtemperature as well as short circuit. They are dimmable and comply with EN55015, EN61347-1 as well as EN61347-2-13. We offer the following types of this Self series: SLD15-300IL-ES, SLD15-350IL-ES, SLD15-500IL-ES and SLD15-700IL-ES. single output output: 15W input voltage: 220 to 240V AC maximal input inrush current: 2A operating temperature: -25 to +50°C service life: 50.000h (Tc = 85°C) dimensions: 85,3x41x22mm weight: 95g

Specifications

manufacturer
Manufacturer's name SLD15-700IL-ES
Output voltage [V] 9...22
Ripple [mAp-p] 37
Efficiency [%] 78,9
Output power [W] 15
Output current [mA] 700
Data Sheet

Unit price

10,49 €

Volume discounts

Quantity Unit price
100 + 8,99 €
50 + 9,39 €

Stock: 144
Further delivery:
CW 16/2025
