8020.0606

Schurter fuse link series SUT 6,3x32

  • time lag (T) fuse links in a 6,3x32mm housing
  • with a low resistance (≤5,6mOhm)
  • comply with UL 248-14
  • suitable for single-phase high current applications (up to 30A)
  • tube made of ceramics and end caps made of nickel-plated brass
  • breaking capacity: 500A
  • rated voltage: 250V AC

8020.0606

235165 8020.0606 8020.0606 Schurter fuse link series SUT 6,3x32. time lag (T) fuse links in a 6,3x32mm housing with a low resistance (≤5,6mOhm) comply with UL 248-14 suitable for single-phase high current applications (up to 30A) tube made of ceramics and end caps made of nickel-plated brass breaking capacity: 500A rated voltage: 250V AC

Specifications

manufacturer
Manufacturer's name 8020.0606
Nominal voltage [V AC] 250
Voltage drop, max. [mV] 62
Melting integral [A²s] 1010
Rated current [A] 25
Resistance [mΩ] 2,1
Data Sheet

Unit price

0,578 €

Stock: 940
Further delivery:
CW 08/2025

Minimum order quantity 10 units or
multiples of 10.
