> Passive elements>Capacitors>Ceramic capacitors>Richwell disc capacitors, pitch 5,08/7,5/10mm, 2000V>K 2200pF 2000V RM10

Manufacturers

K 2200pF 2000V RM10

2000V, pitch: 5.08, 7.5, 10mm

• loose
• rated voltage: 2kV DC
• insulation resistance type 1: 10MΩ
• insulation resistance type 2
20nF: 10MΩ
20nF to 100 nF: 7.5MΩ
• insulation resistance type 3
16V: >100MΩ
25V, 50V: >1MΩ

K_ 2000V

K 2200pF 2000V RM10

35107 K 2200pF 2000V RM10 3D10B222KL02N 3D10B222KL02N 2000V, pitch: 5.08, 7.5, 10mm. • loose• rated voltage: 2kV DC• insulation resistance type 1: 10MΩ• insulation resistance type 220nF: 10MΩ20nF to 100 nF: 7.5MΩ• insulation resistance type 316V: >100MΩ25V, 50V: >1MΩ

Specifications

manufacturer
Manufacturer's name 3D10B222KL02N
Material Y5P
Nominal voltage [V] 2000
Pitch [mm] 10
Tolerance [%] ±10
Capacity [pF] 2200
D [mm] 9,5

Unit price

0,102 €

Stock: 2250
Next incoming goods:
CW 49/2024
2000 units

Further delivery:
CW 15/2025

Minimum order quantity 1 to 50 units or multiples of 100 plus 0 to 50 .
