RPMA5.0-4.5/OF

Recom DC/DC converter series RPMA-4.5

DC/DC converters with open-frame type (PCB) are very compact in size, measuring 19.1x23.4x9.6mm and weighing only 8g, making them ideal for space-constrained applications. These devices have a remote function and a single output that can deliver an output current of up to 4.5A while maintaining maximal output voltage tolerance of ±2%. They operate over a wide temperature range from -40°C to +85°C, ensuring reliable performance even in harsh environments. The DC/DC buck converters come in the popular 1/32 brick format which makes them easy to integrate into existing designs or new projects where board space is at premium without compromising on power density or efficiency levels required by modern electronics systems design standards today! We offer the type RPMA5.0-4.5/OF of this Recom series.

  • single output
  • output current: 4,5A
  • maximal output voltage tolerance: ±2%
  • operating temperature: -40 to +85°C
  • dimensions: 19,1x23,4x9,6mm
  • weight: 8g
RPMA5.0-4.5/OF, Recom DC/DC switching regulators, 4,5A, open frame PCB, RPMA-4.5 series

RPMA5.0-4.5/OF

241450 RPMA5.0-4.5/OF RPMA5.0-4.5/OF Recom DC/DC converter series RPMA-4.5. DC/DC converters with open-frame type (PCB) are very compact in size, measuring 19.1x23.4x9.6mm and weighing only 8g, making them ideal for space-constrained applications. These devices have a remote function and a single output that can deliver an output current of up to 4.5A while maintaining maximal output voltage tolerance of ±2%. They operate over a wide temperature range from -40°C to +85°C, ensuring reliable performance even in harsh environments. The DC/DC buck converters come in the popular 1/32 brick format which makes them easy to integrate into existing designs or new projects where board space is at premium without compromising on power density or efficiency levels required by modern electronics systems design standards today! We offer the type RPMA5.0-4.5/OF of this Recom series. single output output current: 4,5A maximal output voltage tolerance: ±2% operating temperature: -40 to +85°C dimensions: 19,1x23,4x9,6mm weight: 8g

Specifications

manufacturer
Manufacturer's name RPMA5.0-4.5/OF
Input voltage range [V] 9...53
Efficiency [%] 96,5
Ripple [mVp-p] 150
Output voltage range [V] 5...30
Data Sheet
