RACM60-15SK/277/OF-T

Recom power supply series RACM60-K/277/OF

Open frame type switching power supplies (PCB) with 60W, a universal input and a built-in EMI filter. These devices are suitable for medical technology applications (2xMOPP/250V AC) and are protected against overload, overvoltage as well as short circuit. They have a compact size (2"x3") and comply with EN60601-1 class B, EN55032 class B as well as EN61000-4-2. We offer the following types of this Recom series: RACM60-05SK/277/OF-T, RACM60-12SK/277/OF-T, RACM60-15SK/277/OF-T, RACM60-24SK/277/OF-T and RACM60-48SK/277/OF-T.

  • single output
  • output: 40 to 60W
  • input voltage: 80 to 305V AC (47 to 63Hz), 120 to 430V DC
  • maximal input inrush current: 60A
  • no-load power: <0,1W
  • overload protection: 105 to 120%
  • withstand voltage I/P-O/P: 4000V AC
  • operating temperature: -40 to +85°C
  • dimensions: 76,2x50,8x32mm
  • weight: 111g
RACM60-15SK/277/OF-T, Recom switching power supplies, 60W, for medical technology, open frame (PCB), RACM60-K/277/OF series

RACM60-15SK/277/OF-T

241471 RACM60-15SK/277/OF-T RACM60-15SK/277/OF-T Recom power supply series RACM60-K/277/OF. Open frame type switching power supplies (PCB) with 60W, a universal input and a built-in EMI filter. These devices are suitable for medical technology applications (2xMOPP/250V AC) and are protected against overload, overvoltage as well as short circuit. They have a compact size (2"x3") and comply with EN60601-1 class B, EN55032 class B as well as EN61000-4-2. We offer the following types of this Recom series: RACM60-05SK/277/OF-T, RACM60-12SK/277/OF-T, RACM60-15SK/277/OF-T, RACM60-24SK/277/OF-T and RACM60-48SK/277/OF-T. single output output: 40 to 60W input voltage: 80 to 305V AC (47 to 63Hz), 120 to 430V DC maximal input inrush current: 60A no-load power: &lt;0,1W overload protection: 105 to 120% withstand voltage I/P-O/P: 4000V AC operating temperature: -40 to +85°C dimensions: 76,2x50,8x32mm weight: 111g

Specifications

manufacturer
Manufacturer's name RACM60-15SK/...
Output voltage [V] 15
Efficiency [%] 90
Output current [A] 4
Output voltage tolerance: [%] ±1
Output power [W] 60
Data Sheet

Unit price

27,99 €

Stock: 12
Further delivery:
CW 09/2025
