R-735.0P

Recom DC/DC switching regulator series R-7xxx

DC/DC converters in a SIL12 housing with an adjustable output voltage, a built-in switching regulator and an ON/OFF control (ground off). These devices have a synchronous rectification design and are protected against overload as well as short circuit (continuous). They are non-isolated, suitable for PCB mounting and comply with EN60950-1. We offer various types of this Recom series.

  • single output
  • output current: 2 to 4A
  • output voltage tolerance: ±2%
  • maximal ripple and noise: 70mVpp
  • operating temperature: -40 to +85°C
  • weight: 9g
  • R-7_D: THT pins in a 90° angle
R-735.0P, Recom DC/DC switching regulators, 2 to 4A, SIL12 housing, R-7xxx series

R-735.0P

109074 R-735.0P R-735.0P Recom DC/DC switching regulator series R-7xxx. DC/DC converters in a SIL12 housing with an adjustable output voltage, a built-in switching regulator and an ON/OFF control (ground off). These devices have a synchronous rectification design and are protected against overload as well as short circuit (continuous). They are non-isolated, suitable for PCB mounting and comply with EN60950-1. We offer various types of this Recom series. single output output current: 2 to 4A output voltage tolerance: ±2% maximal ripple and noise: 70mVpp operating temperature: -40 to +85°C weight: 9g R-7_D: THT pins in a 90° angle

Specifications

manufacturer
Manufacturer's name R-735.0P
Case SIL12
Input voltage range [V] 6,5...28
Efficiency [%] 95
Output current [mA] 3000
Output voltage range [V] 3...5,5
Data Sheet

Unit price

29,29 €

Stock: 5
Next incoming goods:
CW 49/2024
15 units

Further delivery:
CW 06/2025
