45V25 491µH 1A

Radiohm choke series 45V

Storage/suppression chokes in a plastic housing (UL94V-0) with 1A (45V_ 1A) resp. 3A (45V_ 3A). These chokes are non-potted and suitable for suppressing interference signals in switching power suppplies. They have four tin-plated soldering pins (vertical mount) and reduce grid-bound interferences. We offer the following types of this Radiohm series: 45V20S 127µH 1A, 45V25 345µH 1A, 45V25 491µH 1A, 45V25 49µH 3A, 45V25 75µH 3A and 45V30 157µH 3A.

  • rated voltage: 250V
  • rated current: 1 resp. 3A
  • inductance tolerance: ±20%
  • climatic category: DIN GKC (-40 to +125°C)
  • humidity: category C
  • ambient temperature: up to +60°C
45V25 491UH 1A, Radiohm current-compensated chokes, open mount, vertical, 45V series

45V25 491µH 1A

243880 45V25 491µH 1A 45V25 491UH 1A 45V25 491UH 1A Radiohm choke series 45V. Storage/suppression chokes in a plastic housing (UL94V-0) with 1A (45V_ 1A) resp. 3A (45V_ 3A). These chokes are non-potted and suitable for suppressing interference signals in switching power suppplies. They have four tin-plated soldering pins (vertical mount) and reduce grid-bound interferences. We offer the following types of this Radiohm series: 45V20S 127µH 1A, 45V25 345µH 1A, 45V25 491µH 1A, 45V25 49µH 3A, 45V25 75µH 3A and 45V30 157µH 3A. rated voltage: 250V rated current: 1 resp. 3A inductance tolerance: ±20% climatic category: DIN GKC (-40 to +125°C) humidity: category C ambient temperature: up to +60°C

Specifications

manufacturer
Manufacturer's name 45V25 491UH 1A
Design vertical
Rated current [A] 1
Inductance [µH] 491
Data Sheet

Unit price

1,78 €

Stock: 360
Further delivery:
CW 05/2025

Minimum order quantity 10 units or
multiples of 10.
