PSAC05R-050-L6

Phihong plug-in power supply series PSAC05R

Universal plug-in switching power supplies with 5W, insulation class II, a low no-load power and energy efficiency Level VI. These devices are protected against overload as well as short circuit and comply with EN55024, EN61000-3-2 as well as EN61000-4-2. We offer the following types of this Phihong series: PSAC05R-050-L6 and PSAC05R-050-L6-M.

  • single output
  • output: 5W
  • input voltage: 90 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 30A
  • cable length: 1,5m
  • output plug PSAC05R-050-L6: 2,1x5,5mm
  • output plug PSAC05R-050-L6-M: Micro-USB-B
  • operating temperature: 0 to +40°C
  • weight: 120g

Matching input plugs

PSAC05R-050-L6

PSAC05R-050-L6

107138 PSAC05R-050-L6 PSAC05R-050L6 PSAC05R-050L6 Phihong plug-in power supply series PSAC05R. Universal plug-in switching power supplies with 5W, insulation class II, a low no-load power and energy efficiency Level VI. These devices are protected against overload as well as short circuit and comply with EN55024, EN61000-3-2 as well as EN61000-4-2. We offer the following types of this Phihong series: PSAC05R-050-L6 and PSAC05R-050-L6-M. single output output: 5W input voltage: 90 to 264V AC (47 to 63Hz) maximal input inrush current: 30A cable length: 1,5m output plug PSAC05R-050-L6: 2,1x5,5mm output plug PSAC05R-050-L6-M: Micro-USB-B operating temperature: 0 to +40°C weight: 120g Matching input plugs

Specifications

manufacturer
Manufacturer's name PSAC05R-050L6
Output voltage [V] 5
Efficiency [%] DOE VI
Output current [A] 0...1
Output voltage tolerance: [%] 1
Output power [W] 5
Ripple [mVp-p] 200
Data Sheet

Unit price

6,59 €

Stock: 25
Further delivery:
CW 33/2025
