POE29U-1AT(PL)D

Phihong desktop power supply series POE29U

PoE injectors with 30W, a universal input, protection class I and a single port. These desktop switching power supplies are able to supply devices with voltage through the data line and are protected against overload, overvoltage as well as short circuit. They have an LED status display and comply with IEC60950-1, IEC62368-1, UL60950-1, UL62368-1, EN55032 class B as well as IEEE802.3at (PoE+). We offer the type POE29U-1AT(PL)D of this Phihong series.

  • single output
  • output: 30W
  • input voltage: 90 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 60A
  • input current: 0,55A
  • leakage current: 3,5mA
  • data rate: 1Gb
  • withstand voltage: 1500V AC
  • operating temperature: -20 to +50°C
  • input plug: C14
  • output plug: RJ45
  • dimensions: 140x65x36mm
  • weight: 220g
POE29U-1AT(PL)D, Phihong PoE desktop switching power supplies, 30W, POE29U series

POE29U-1AT(PL)D

236111 POE29U-1AT(PL)D POE29U-1AT(PL)D Phihong desktop power supply series POE29U. PoE injectors with 30W, a universal input, protection class I and a single port. These desktop switching power supplies are able to supply devices with voltage through the data line and are protected against overload, overvoltage as well as short circuit. They have an LED status display and comply with IEC60950-1, IEC62368-1, UL60950-1, UL62368-1, EN55032 class B as well as IEEE802.3at (PoE+). We offer the type POE29U-1AT(PL)D of this Phihong series. single output output: 30W input voltage: 90 to 264V AC (47 to 63Hz) maximal input inrush current: 60A input current: 0,55A leakage current: 3,5mA data rate: 1Gb withstand voltage: 1500V AC operating temperature: -20 to +50°C input plug: C14 output plug: RJ45 dimensions: 140x65x36mm weight: 220g

Specifications

manufacturer
Manufacturer's name POE29U-1AT(PL)D
Output voltage [V] 56
Efficiency [%] 80
Output current [A] 0,536
Output power [W] 30
Data Sheet

Unit price

31,79 €

Stock: 31
Further delivery:
CW 33/2025
