> Passive elements>Capacitors>Electrolytic capacitors>Panasonic solid capacitors, radial, 125°C, OS-CON, SEF series>20SEF560M

Manufacturers

20SEF560M

Panasonic solid capacitor series SEF

  • halogen free radial OS-CON polymer aluminium solid capacitors
  • highly conductive polymers provide an excellent noise reduction capability and an ideal frequency characteristic
  • with a long service life (1000h at +125°C), a high reliability and a high heat resistance (-55 to +125°C)
  • capacitance tolerance: ±20%
  • taped
20SEF560M, Panasonic solid capacitors, radial, 125°C, OS-CON, SEF series

20SEF560M

122130 20SEF560M 20SEF560M Panasonic solid capacitor series SEF. halogen free radial OS-CON polymer aluminium solid capacitors  highly conductive polymers provide an excellent noise reduction capability and an ideal frequency characteristic with a long service life (1000h at +125°C), a high reliability and a high heat resistance (-55 to +125°C) capacitance tolerance: ±20% taped

Specifications

manufacturer
Manufacturer's name 20SEF560M
Nominal voltage [V DC] 20
Diameter [mm] 10
Capacity [µF] 560
Pitch [mm] 5
Length [mm] 13
Data Sheet

Unit price

1,06 €

Stock: 375
Further delivery:
CW 39/2025

Minimum order quantity 25 units or
multiples of 25.
