EEUFR1A562L

Panasonic electrolytic capacitor series FR

  • aluminium eletrolytic capacitors
  • radial type
  • with a service life of 5000 to 10 000h at 105°C
  • operating temperature: -40 to +105°C
  • capacitance tolerance: ±20%
  • bulk and taped (EEUFR_B)
EEUFR1A562L, Panasonic electrolytic capacitors, radial, 105°C, low ESR, FR series

EEUFR1A562L

36962 EEUFR1A562L EEUFR1A562L Panasonic electrolytic capacitor series FR. aluminium eletrolytic capacitors radial type with a service life of 5000 to 10 000h at 105°C operating temperature: -40 to +105°C capacitance tolerance: ±20% bulk and taped (EEUFR_B)

Specifications

manufacturer
Manufacturer's name EEUFR1A562L
Design loose
Ripple Current (105°C, 100kHz) [mA] 3750
Diameter [mm] 12,5
Nominal voltage [V] 10
Capacity [µF] 5600
Pitch [mm] 5
Length [mm] 35
Data Sheet

Unit price

0,964 €

Stock: 100
Next incoming goods:
CW 04/2025
300 units

Further delivery:
CW 18/2025

Minimum order quantity 50 units or
multiples of 50.
