EEEFK0J220AR

Panasonic capacitor series FK

  • low ESR electrolytic capacitors (SMD)
  • suitable for high temperature lead-free reflow soldering
  • operating temperature: -55 to +105°C
  • capacitance tolerance: ±20%
  • service life (at 105°C) EEEFK_AP/EEEFK_AR: 2000h
  • service life (at 105°C) EEEFK_AQ/EEEFK_AM: 1000h
  • taped
EEEFK0J220AR, Panasonic electrolytic capacitors, SMD, 105°, reflow, low ESR, 2000h, FK series

EEEFK0J220AR

36705 EEEFK0J220AR EEEFK0J220AR Panasonic capacitor series FK. low ESR electrolytic capacitors (SMD) suitable for high temperature lead-free reflow soldering operating temperature: -55 to +105°C capacitance tolerance: ±20% service life (at 105°C) EEEFK_AP/EEEFK_AR: 2000h service life (at 105°C) EEEFK_AQ/EEEFK_AM: 1000h taped

Specifications

manufacturer
Manufacturer's name EEEFK0J220AR
Reverse current [mA] 90
Nominal voltage [V DC] 6,3
Impedance [Ω] 13,5
Loss factor at 120Hz, 20°C 0,26
Capacity [µF] 22
D [mm] 4
Data Sheet

Unit price

0,12 €

Stock: 1900
Further delivery:
CW 22/2025

Minimum order quantity 100 units or
multiples of 100.
