> Passive elements>Capacitors>Electrolytic capacitors>Panasonic electrolytic capacitors, SMD, 105°, reflow, low ESR, 2000h, FK series>EEEFK1A222AQ

Manufacturers

EEEFK1A222AQ

Panasonic capacitor series FK

  • low ESR electrolytic capacitors (SMD)
  • suitable for high temperature lead-free reflow soldering
  • operating temperature: -55 to +105°C
  • capacitance tolerance: ±20%
  • service life (at 105°C) EEEFK_AP/EEEFK_AR: 2000h
  • service life (at 105°C) EEEFK_AQ/EEEFK_AM: 1000h
  • taped
EEEFK1A222AQ, Panasonic electrolytic capacitors, SMD, 105°, reflow, low ESR, 2000h, FK series

EEEFK1A222AQ

110808 EEEFK1A222AQ EEEFK1A222AQ Panasonic capacitor series FK. low ESR electrolytic capacitors (SMD) suitable for high temperature lead-free reflow soldering operating temperature: -55 to +105°C capacitance tolerance: ±20% service life (at 105°C) EEEFK_AP/EEEFK_AR: 2000h service life (at 105°C) EEEFK_AQ/EEEFK_AM: 1000h taped

Specifications

manufacturer
Manufacturer's name EEEFK1A222AQ
Nominal voltage [V DC] 10
Impedance [Ω] 0,06
Loss factor at 120Hz, 20°C 0,21
Capacity [µF] 2200
D [mm] 12,5
Length [mm] 13,5
Data Sheet

Unit price

0,749 €

Stock: 1600
Further delivery:
CW 18/2025

Minimum order quantity 100 units or
multiples of 100.
