> Passive elements>Capacitors>Electrolytic capacitors>Panasonic electrolytic capacitors, SMD, 105°, reflow, low ESR, 2000h, FK series>EEEFK0J332AQ

Manufacturers

EEEFK0J332AQ

Panasonic capacitor series FK

  • low ESR electrolytic capacitors (SMD)
  • suitable for high temperature lead-free reflow soldering
  • operating temperature: -55 to +105°C
  • capacitance tolerance: ±20%
  • service life (at 105°C) EEEFK_AP/EEEFK_AR: 2000h
  • service life (at 105°C) EEEFK_AQ/EEEFK_AM: 1000h
  • taped
EEEFK0J332AQ, Panasonic electrolytic capacitors, SMD, 105°, reflow, low ESR, 2000h, FK series

EEEFK0J332AQ

110807 EEEFK0J332AQ EEEFK0J332AQ Panasonic capacitor series FK. low ESR electrolytic capacitors (SMD) suitable for high temperature lead-free reflow soldering operating temperature: -55 to +105°C capacitance tolerance: ±20% service life (at 105°C) EEEFK_AP/EEEFK_AR: 2000h service life (at 105°C) EEEFK_AQ/EEEFK_AM: 1000h taped

Specifications

manufacturer
Manufacturer's name EEEFK0J332AQ
Nominal voltage [V DC] 6,3
Impedance [Ω] 0,6
Loss factor at 120Hz, 20°C 0,3
Capacity [µF] 3300
D [mm] 12,5
Length [mm] 13,5
Data Sheet

Unit price

0,857 €

Stock: 500
Further delivery:
CW 22/2025

Minimum order quantity 100 units or
multiples of 100.
