NF104-001E12SR

NF motor vehicle relays series NF104

These sealed relays have small demensions but they still are suitable for heavy contact load (40A). They are available in a type for PC board mounting (NF104-100E12SP) and in a type for direct insert mounting (NF104-000E12SP). We offer the following types of this Nf series: NF104-001E12SR and NF104-100E12SP.

  • maximal switching current: 40A
  • switching power: 630W
  • maximal switching voltage: 75V DC
  • contact type: 1x changeover (NF104-001_), 1x normally open contact (NF104-100_)
  • contact material: AgSnO
  • contact resistance: 30mOhm
  • isolation resistance: 100MOhm
  • operate / drop out time: 7/5ms
  • test voltage: 500V (inductor / contact), 500V (contact / contact)
  • endurance: 107 (mechanical), 105 (electrical)
  • vibration resistance: 1,5mm DA
  • operating temperature: -40 to +125°C
  • weight: 31g
  • dimensions: 26,5x26,5x24,5mm
NF104-001E12SR, NF motor vehicle relays, 40A, 1 changeover or 1 normally open contact, NF104 series

NF104-001E12SR

246918 NF104-001E12SR NF104-001E12SR NF motor vehicle relays series NF104. These sealed relays have small demensions but they still are suitable for heavy contact load (40A). They are available in a type for PC board mounting (NF104-100E12SP) and in a type for direct insert mounting (NF104-000E12SP). We offer the following types of this Nf series: NF104-001E12SR and NF104-100E12SP. maximal switching current: 40A switching power: 630W maximal switching voltage: 75V DC contact type: 1x changeover (NF104-001_), 1x normally open contact (NF104-100_) contact material: AgSnO contact resistance: 30mOhm isolation resistance: 100MOhm operate / drop out time: 7/5ms test voltage: 500V (inductor / contact), 500V (contact / contact) endurance: 107 (mechanical), 105 (electrical) vibration resistance: 1,5mm DA operating temperature: -40 to +125°C weight: 31g dimensions: 26,5x26,5x24,5mm

Specifications

manufacturer
Manufacturer's name NF104-001E12SR
Nominal voltage [V DC] 12
Coil resistance [Ω] 90
Max. operating voltage [V DC] 15,6
Response voltage [V] 7,8
Nominal capacity [mW] 1600
Data Sheet

Unit price

2,09 €

Stock: 90
Further delivery:
CW 18/2025

Minimum order quantity 10 units or
multiples of 10.
