44706

Myrra PCB transformers

Transformers with 2,8VA and an EI30 core. These devices are short circuit proof and suitable for PCB mounting. They comply with temperature resistance class Ta 70/B as well as EN61558-2-6 and EN60950. We offer the following types of this Myrra series: 44697, 44698, 44699, 44700, 44701, 44702, 44703, 44704, 44705 and 4706.

  • core: EI 30
  • output: 2,8VA
  • input voltage: 230V AC (50/60Hz)
  • temperature class: Ta 70/B
  • test voltage: 4kV
44706, print transformers, 2.8VA

44706

112703 44706 44706 Myrra PCB transformers. Transformers with 2,8VA and an EI30 core. These devices are short circuit proof and suitable for PCB mounting. They comply with temperature resistance class Ta 70/B as well as EN61558-2-6 and EN60950. We offer the following types of this Myrra series: 44697, 44698, 44699, 44700, 44701, 44702, 44703, 44704, 44705 and 4706. core: EI 30 output: 2,8VA input voltage: 230V AC (50/60Hz) temperature class: Ta 70/B test voltage: 4kV

Specifications

manufacturer
Manufacturer's name 44706
Secondary current [mA] 2x187
Secondary voltage [V] 2x15
Data Sheet

Unit price

2,09 €

Stock: 175
Further delivery:
CW 12/2025
