> Passive elements>Transformers>PCB transformers>Myrra PCB transformers, 2,8VA, EI 30>44705

Manufacturers

44705

Myrra PCB transformers

Transformers with 2,8VA and an EI30 core. These devices are short circuit proof and suitable for PCB mounting. They comply with temperature resistance class Ta 70/B as well as EN61558-2-6 and EN60950. We offer the following types of this Myrra series: 44697, 44698, 44699, 44700, 44701, 44702, 44703, 44704, 44705 and 4706.

  • core: EI 30
  • output: 2,8VA
  • input voltage: 230V AC (50/60Hz)
  • temperature class: Ta 70/B
  • test voltage: 4kV
44705, print transformers, 2.8VA

44705

112702 44705 44705 Myrra PCB transformers. Transformers with 2,8VA and an EI30 core. These devices are short circuit proof and suitable for PCB mounting. They comply with temperature resistance class Ta 70/B as well as EN61558-2-6 and EN60950. We offer the following types of this Myrra series: 44697, 44698, 44699, 44700, 44701, 44702, 44703, 44704, 44705 and 4706. core: EI 30 output: 2,8VA input voltage: 230V AC (50/60Hz) temperature class: Ta 70/B test voltage: 4kV

Specifications

manufacturer
Manufacturer's name 44705
Secondary current [mA] 2x233
Secondary voltage [V] 2x12
Data Sheet

Unit price

2,09 €

Stock: 162
Next incoming goods:
CW 07/2025
75 units

Further delivery:
CW 12/2025
