NMS 1212

Murata DC/DC converter series NMS

Isolated DC/DC converter modules with 2A and two outputs. These device do not require an additional heat sink and have a low profile. They are suitable for PCB mounting and are flame-retardant (UL94V-0). We offer the type NMS1212C of this Murata / C&D Technologies series.

  • dual output
  • output: 2W
  • input voltage: 10,8 to 13,2V
  • output voltage: ±12V
  • output current: ±83mA
  • isolation voltage: 6000V DC
NMS1212C, Murata DC/DC converters, 2W, dual output, CD, NMS series

NMS 1212

18199 NMS 1212 NMS1212C NMS1212C Murata DC/DC converter series NMS. Isolated DC/DC converter modules with 2A and two outputs. These device do not require an additional heat sink and have a low profile. They are suitable for PCB mounting and are flame-retardant (UL94V-0). We offer the type NMS1212C of this Murata / C&D Technologies series. dual output output: 2W input voltage: 10,8 to 13,2V output voltage: ±12V output current: ±83mA isolation voltage: 6000V DC

Discontinued items. Only remainder of stock available.

Specifications

manufacturer
Manufacturer's name NMS1212C
Data Sheet

Unit price

24,20 €

Stock: 10
