PSG 3,96 15-polig

MPE Garry pin header series 580

Straight male headers for crimp connectors with tinned brass contacts. These pin strips have an insulator made of polyamide 6.6 (UL94V-0) and have a pitch of 3,96mm. They are suitable for 250VRMS/V DC as well as 5A. We offer the following types of this MPE Garry series: 580-3-002-0-T-BS0, 580-3-003-0-T-BS0, 580-3-004-0-T-BS0, 580-3-005-T-BS0, 580-3-006-0-T-BS0, 580-3-007-0-T-BS0, 580-3-008-0-T-BS0, 580-3-009-0-T-BS0 and 580-3-015-0-T-BS0.

  • pitch: 3,96mm
  • number of poles: 2 to 15
  • rated voltage: 250VRMS/V DC
  • rated current: 5A
  • dielectric strength (1min): 1500VRMS
  • operating temperature: -25 to +85°C

Matching crimp connectors

580-3-015-0-T-BS0, MPE Garry pin headers, straight, 3,96mm, 580 series

PSG 3,96 15-polig

244226 PSG 3,96 15-polig 580-3-015-0-T-BS0 580-3-015-0-T-BS0 MPE Garry pin header series 580. Straight male headers for crimp connectors with tinned brass contacts. These pin strips have an insulator made of polyamide 6.6 (UL94V-0) and have a pitch of 3,96mm. They are suitable for 250VRMS/V DC as well as 5A. We offer the following types of this MPE Garry series: 580-3-002-0-T-BS0, 580-3-003-0-T-BS0, 580-3-004-0-T-BS0, 580-3-005-T-BS0, 580-3-006-0-T-BS0, 580-3-007-0-T-BS0, 580-3-008-0-T-BS0, 580-3-009-0-T-BS0 and 580-3-015-0-T-BS0. pitch: 3,96mm number of poles: 2 to 15 rated voltage: 250VRMS/V DC rated current: 5A dielectric strength (1min): 1500VRMS operating temperature: -25 to +85°C Matching crimp connectors

Specifications

manufacturer
Manufacturer's name 580-3-015-0-T-BS0
Number of poles 15
A [mm] 59,4
Width [mm] 55,4
Data Sheet

Unit price

1,24 €

Stock: 2500
Further delivery:
CW 28/2025

Minimum order quantity 50 units or
multiples of 50.
