PSA 3,96 7-polig

MPE Garry pin header series 580

  • angled type nylon pin strips (90°)
  • insulator made of nylon 66 (UL94V-0)
  • with tinned contacts made of brass
  • temperature range: -25 to +85°C
  • dielectric strength (1min): 1500VAC
  • rated current: 5A
  • rated voltage: 250VRMS/VDC
  • pitch: 3,96mm

Matching connectors

580-2-007-0-T-BS0, MPE Garry pin headers, angled, 3,96mm, 580 series

PSA 3,96 7-polig

235536 PSA 3,96 7-polig 580-4-007-0-T-BS0 580-4-007-0-T-BS0 MPE Garry pin header series 580. angled type nylon pin strips (90°) insulator made of nylon 66 (UL94V-0) with tinned contacts made of brass temperature range: -25 to +85°C dielectric strength (1min): 1500VAC rated current: 5A rated voltage: 250VRMS/VDC pitch: 3,96mm Matching connectors

Specifications

manufacturer
Manufacturer's name 580-4-007-0-T-BS0
Number of poles 7
A [mm] 27,72
Width [mm] 23,76
Data Sheet

Unit price

0,616 €

Stock: 5000
Further delivery:
CW 28/2025

Minimum order quantity 50 units or
multiples of 50.
