ML 20 GL LC

box headers

* straight
* colour: black
* pitch: 2.54mm
* polyester, fibreglass-reinforced UL94V-0
* contact material: phosphor-bronze
* contact surface: selective gold over nickel
* rated current: 1A
* test voltage: 1000Veff
* insulation resistance, min.: 1000MΩ
* temperature range: -20...+70°C
ML 20 GL LC

ML 20 GL LC

28162 ML 20 GL LC 092-2-020-0-F-KS0 092-2-020-0-F-KS0 box headers. * straight* colour: black* pitch: 2.54mm* polyester, fibreglass-reinforced UL94V-0* contact material: phosphor-bronze* contact surface: selective gold over nickel* rated current: 1A* test voltage: 1000Veff* insulation resistance, min.: 1000MΩ* temperature range: -20...+70°C

Specifications

manufacturer
Manufacturer's name 092-2-020-0-F-KS0
Number of poles 20
A [mm] 44,7
Width [mm] 34,54
C [mm] 22,86

Unit price

0,576 €

Stock: 7405
Next incoming goods:
CW 04/2025
4428 units

Further delivery:
CW 28/2025

Minimum order quantity 1 unit or multiples of 12 plus 0 to 1 .
