STL 1-1470AGT-050U

high quality pin headers

• single row, angled
• pitch: 2.54mm
• thermoplastic, UL94V-0
• contact material (DIN17660): CuZn
• rated current: 3A
• pin cross section: 0.635x0.635mm
• by: MPE Garry
• test voltage: 250V AC
• insulation resistance, min.: 500MΩ
• temperature range: -40...+105°C
• peak(10s): +260°C
• solderability: IEC 68-2-20 Tb
• pin length, A): 14.7mm
• pin length plug-in area (B): 6.9mm
• pin length solderin area (C): 3.3mm

STL 1-1470AGT-050U

STL 1-1470AGT-050U

32892 STL 1-1470AGT-050U 088-1-050-0-S-XS0-1080 088-1-050-0-S-XS0-1080 high quality pin headers. • single row, angled• pitch: 2.54mm• thermoplastic, UL94V-0• contact material (DIN17660): CuZn• rated current: 3A• pin cross section: 0.635x0.635mm• by: MPE Garry• test voltage: 250V AC• insulation resistance, min.: 500MΩ• temperature range: -40...+105°C• peak(10s): +260°C• solderability: IEC 68-2-20 Tb• pin length, A): 14.7mm• pin length plug-in area (B): 6.9mm• pin length solderin area (C): 3.3mm

Specifications

manufacturer
Manufacturer's name 088-1-050-0-...
Type teilvergoldet
Number of poles 50
Data Sheet

Unit price

2,09 €

Stock: 148
Further delivery:
CW 22/2025

Minimum order quantity 1 to 8 units or multiples of 10 plus 0 to 8 .
