MWMB10E-L

Minwa plug-in power supply series MWM_EU

Plug-in switching power supplies with 7,2/12W, insulation class II, a Europlug, energy efficiency Level VI, a universal input and a low no-load power. These devices are suitable for various jack/coaxial plugs and are protected against overload, overvoltage as well as short circuit. They have a selectable output voltage and comply with EN61558-2-16 as well as EN61204-3. We offer the following types of this Minwa series: MW MA06EU-L, MW MA06EU-H and MW MB10E-H.

  • single output
  • output: 7,2 to 12W
  • input voltage: 100 to 240V AC (50/60Hz)
  • no-load power: <0,1W
  • operating temperature: 0 to +25°C
  • cable length: 1,8m
MWMB10E-L, Minwa plug-in switching power supplies, 7,2 to 12W, MWM_EU series

MWMB10E-L

247593 MWMB10E-L MWMB10E-L Minwa plug-in power supply series MWM_EU. Plug-in switching power supplies with 7,2/12W, insulation class II, a Europlug, energy efficiency Level VI, a universal input and a low no-load power. These devices are suitable for various jack/coaxial plugs and are protected against overload, overvoltage as well as short circuit. They have a selectable output voltage and comply with EN61558-2-16 as well as EN61204-3. We offer the following types of this Minwa series: MW MA06EU-L, MW MA06EU-H and MW MB10E-H. single output output: 7,2 to 12W input voltage: 100 to 240V AC (50/60Hz) no-load power: &lt;0,1W operating temperature: 0 to +25°C cable length: 1,8m

Specifications

manufacturer
Manufacturer's name MWMB10E-L
Output voltage [V] 3/4,5/5/6/7,5/9/12
Efficiency [%] 65/67,9/68,9...
Output current [A] 2/2//2/1,5/1...
Output power [W] 12
Data Sheet

Unit price

9,89 €

Stock: 0
Further delivery:
CW 18/2025
