WDR-60-24

Mean Well DIN rail power supply series WDR-60

DIN rail power supplies with a universal input (1- or 2-phase), cooling by free air convection and 60W. These devices can be mounted directly on a DIN rail, have an adjustable DC output voltage and a built-in DC OK relay contact. They are protected against short circuit, overload, overvoltage (overvoltage category III) and comply with insulation class II as well as EN55032 class B and EN61000-3-2,3. We offer the following types of this Mean Well series: WDR-60-5, WDR-60-12, WDR-60-24 and WDR-60-48.

  • single output
  • output: 50 to 60W
  • input voltage: 180 to 550V AC (47 to 63Hz), 254 to 780V DC
  • maximal input inrush current: 50A
  • maximal leakage current: 2mA
  • output voltage adjustment: +20%
  • overload protection: 105 to 135%
  • withstand voltage I/P-O/P: 4700V AC
  • withstand voltage I/P-FG: 2500V AC
  • withstand voltage O/P-FG: 500V AC
  • operating temperature: -30 to +85°C
  • weight: 450g
WDR-60-24, Mean Well DIN rail switching power supplies, 60W, 2-phase input, WDR-60 series

WDR-60-24

119244 WDR-60-24 WDR-60-24 4711287422541 Mean Well DIN rail power supply series WDR-60. DIN rail power supplies with a universal input (1- or 2-phase), cooling by free air convection and 60W. These devices can be mounted directly on a DIN rail, have an adjustable DC output voltage and a built-in DC OK relay contact. They are protected against short circuit, overload, overvoltage (overvoltage category III) and comply with insulation class II as well as EN55032 class B and EN61000-3-2,3. We offer the following types of this Mean Well series: WDR-60-5, WDR-60-12, WDR-60-24 and WDR-60-48. single output output: 50 to 60W input voltage: 180 to 550V AC (47 to 63Hz), 254 to 780V DC maximal input inrush current: 50A maximal leakage current: 2mA output voltage adjustment: +20% overload protection: 105 to 135% withstand voltage I/P-O/P: 4700V AC withstand voltage I/P-FG: 2500V AC withstand voltage O/P-FG: 500V AC operating temperature: -30 to +85°C weight: 450g

Specifications

manufacturer
Manufacturer's name WDR-60-24
GTIN 4711287422541
Output voltage [V] 24
Efficiency [%] 89
Output current range [A] 0...2,5
Output voltage tolerance: [%] 1
Output power [W] 60
Ripple [mVp-p] 150
Data Sheet

Unit price

34,79 €

Volume discounts

Quantity Unit price
50 + 33,89 €

Stock: 934
