VFD-350C-230

Mean Well variable frequency drive series VFD-350C-230

Variable frequency drives (VFDs) in an enclosed housing with 350W and a peak load capability of up to 200%. These devices have a built-in active PFC function, can be controlled with an external PWM signal and are protected against short circuit. They have sensors for monitoring current, bus voltage as well as temperature, are suitable for motors with a 3-phase control and comply with EN61800-5 as well as EN61800-3 class A. We offer the type VFD-350C-230 of this Mean Well series.

  • output: 350W
  • input voltage: 90 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 50A
  • leakage current: <2mA
  • operating temperature: -30 to +60°C
  • dimensions: 146x62x31mm
  • weight: 0,38kg
VFD-350C-230, Mean Well variable frequency drives, 350W, enclosed, VFD-350C-230 series

VFD-350C-230

244428 VFD-350C-230 VFD-350C-230 Mean Well variable frequency drive series VFD-350C-230. Variable frequency drives (VFDs) in an enclosed housing with 350W and a peak load capability of up to 200%. These devices have a built-in active PFC function, can be controlled with an external PWM signal and are protected against short circuit. They have sensors for monitoring current, bus voltage as well as temperature, are suitable for motors with a 3-phase control and comply with EN61800-5 as well as EN61800-3 class A. We offer the type VFD-350C-230 of this Mean Well series. output: 350W input voltage: 90 to 264V AC (47 to 63Hz) maximal input inrush current: 50A leakage current: &lt;2mA operating temperature: -30 to +60°C dimensions: 146x62x31mm weight: 0,38kg

Specifications

manufacturer
Manufacturer's name VFD-350C-230
Output voltage [V] 0...240
Efficiency [%] 93
Output current [A] 1,4
Output power [W] 350
Data Sheet

Unit price

40,69 €

Volume discounts

Quantity Unit price
50 + 39,39 €

Stock: 10
Further delivery:
CW 12/2025
