SRS-4805

Mean Well DC/DC converters series SRS

DC/DC converters in a DIP/DIL16 case, with 0,5W, a cooling mechanism, auto recovery (hiccup), as well as they are protected against overload and short circuit. These voltage converters can be installed directly on the PCB and they convey with the EMV norms of EN55032 class B. We offer the following types of this Mean Well series: SRS-0505, SRS-1205, SRS-2405, SRS-4805, SRS-0509, SRS1209, SRS-2409, SRS-4809, SRS-0512, SRS1212, SRS-24-12, SRS-4812, SRS-0515, SRS-1215, SRS-2415, and SRS-4815.

  • single output
  • voltageoutput: 0,5W
  • input voltage ratio: 1:1
  • maximum ripple: 100mVp-p
  • isolation voltage: 1000V DC
  • operating temperature: -25 to +71 °C
  • dimensions: 22,6x9,9x8,4mm
  • weight: 3,1g
SRS-4805, Man Well DC/DC converters, 0,5W, DIP/DIL16 case, SRS series

SRS-4805

246483 SRS-4805 SRS-4805 4711287479729 Mean Well DC/DC converters series SRS. DC/DC converters in a DIP/DIL16 case, with 0,5W, a cooling mechanism, auto recovery (hiccup), as well as they are protected against overload and short circuit. These voltage converters can be installed directly on the PCB and they convey with the EMV norms of EN55032 class B. We offer the following types of this Mean Well series: SRS-0505, SRS-1205, SRS-2405, SRS-4805, SRS-0509, SRS1209, SRS-2409, SRS-4809, SRS-0512, SRS1212, SRS-24-12, SRS-4812, SRS-0515, SRS-1215, SRS-2415, and SRS-4815. single output voltageoutput: 0,5W  input voltage ratio: 1:1 maximum ripple: 100mVp-p isolation voltage: 1000V DC operating temperature: -25 to +71 °C dimensions: 22,6x9,9x8,4mm weight: 3,1g

Specifications

manufacturer
Manufacturer's name SRS-4805
GTIN 4711287479729
Output voltage [V] 5
Input voltage range [V] 43,2...52,8
Efficiency [%] 60
Output current [A] 0...100
Data Sheet

Unit price

4,59 €

Stock: 0
Further delivery:
CW 23/2025
